15" XGA TFT Fanless Touch Panel Computer with Intel® Celeron® Processor N3350 or Intel® Pentium® Processor N4200

工业平板电脑

GOT115-319

15" XGA TFT Fanless Touch Panel Computer with Intel® Celeron® Processor N3350 or Intel® Pentium® Processor N4200

产品规格

LCD Panel
  • 15" XGA TFT LCD
  • 300 nits (XGA)
  • 1024 x 768 pixels
CPU
  • Intel® Celeron® processor N3350 (up to 2.4 GHz)
  • Intel® Pentium® processor N4200 (up to 2.5 GHz)
Chipset
  • SoC integrated
System Memory
  • 1 x 204-pin DDR3L-1600 SO-DIMM, up to 8GB
BIOS
  • AMI
COM
  • 1 x RS-232/422/485 (default RS-232)
  • 1 x RS-232
USB
  • 2 x USB 3.0
  • 2 x USB 2.0
Ethernet
  • 2 x 10/100/1000 Mbps
Display
  • N/A
Audio
  • 1 x Audio (Line-out)
Storage
  • 1 x 2.5" SATA HDD (9.5 mm height)
  • 1 x mSATA
  • 1 x MicroSD card
Expansion
  • 1 x M.2 Key E for wireless module
  • 1 x Full-size PCI Express Mini Card slot
Others
  • 1 x Screw type connector for power
  • 1 x Power button (ATX)
  • 1 x Remote power switch
  • 1 x ATX/AT selectable switch
  • Speaker
  • Microphone
Touchscreen
  • Projected capacitive multi-touch
  • 5-wire flat resistive touch
Front Bezel
  • IP65, NEMA 4 rugged protection, plastic front bezel
Power Supply
  • 9 to 24 VDC with adapter cable
Power Comsumption
  • 28.8W
Watchdog Timer
  • 255 levels, 0 to 255 sec.
Operating Temperature
  • 0°C to +50°C (+32°F to +122°F)
Relative Humidity
  • 10% - 90% @ +40°C; non-condensing
Vibration
  • 2G, 5 - 500Hz, random for SSD
Dimensions
(W x D x H)
  • 329.69 x 50 x 306 mm (13" x 2" x 12")
Weight (net/gross)
  • 3.2 kg (7.1 lb)/4.8 kg (10.6 lb)
Certifications
  • CE
EOS
  • Windows® 10
Mounting
  • Panel mount kit
  • Wall mount kit
  • Stand kit
